产品型号： | PT-8010 |
| 产品品牌： | 台湾品致PINTECH | |
| 产品价格： | 面议 | |
| 所 在 地： | 广东 广州市 | |
| 发布日期： | 2018-06-07 | |
 |
||
详细说明
规格
频宽 70MHz
误差 ±2%
输入阻抗 10MΩ//7 p F each side ground
输入电压
-Swing(into 50 KΩ load) ±7V
-Offset(typical) ＜±5mV
-杂讯（typical） 0.9 mV rms
-输入阻抗(typical) 50Ω
共模互斥比CARR(typical) -80dB @50Hz；-60d B@1MHz
供应电源
-内置 4×AA cells or 6V DC/70m A mains adaptor or regulated 9V DC/120m A mains adaptor
-外接 power leads
BNC长度 90cm
测试线长度 60cm
重量 500g
尺寸(L×W×H) 202mm×83mm×38mm
型号 PT-8010 PT-8020
衰减比例 1:100/1000 1:200/2000
最大输入差分电压
(DC+ Peak AC) ±700V@1/100
±7000V@1/1000 ±1400@1/200
±14000@1/2000
最大输入与地电位差
(DC+Peak AC) ±7000V@1/100＆ 1/1000 ±7000V@1/200 ＆ 1/2000
共模互斥比（CMRR） 2500V rms CAT Ⅲ 2500V rms CAT Ⅲ
Specifications
Bandwidth 70MHz
Accuracy ±2%
Input Impedance 10KΩ//7 p F each side ground
Output Voltage
-Swing(into 50 KΩ load) ±7V
-Offset(typical) ＜±5mV
-Noise（typical） 0.9 mV rms
-Source Impedance(typical) 50Ω
CARR(typical) -80dB @50Hz；-60d B@1MHz
Power Requirements
-Standard 4×AA cells or 6V DC/70m A mains adaptor or regulated 9V DC/120m A mains adaptor
-Options power leads
Length of BNC Lead 90cm
Length of Input Leads 60cm
Weighr 500g
Dimension(L×W×H) 202mm×83mm×38mm
Specifications PT-8010 PT-8020
Attenuation Ratio 1:100/1000 1:200/2000
Differential Input Voltage
(DC+ Peak AC) ±700V@1/100
±7000V@1/1000 ±1400@1/200
±14000@1/2000
Common Mode Voltage
(DC+Peak AC) ±7000V@1/100＆ 1/1000 ±7000V@1/200 ＆ 1/2000
Absolute Max .Input
(Each side to ground) 2500V rms CAT Ⅲ 2500V rms CAT Ⅲ
Features:
•Up to ±1400V(DC+Peak AC) Differential
•Bandwidth up to 70MHz
•Safety Certified
•Overrange Indicator
Applicstions:
•High Voltage Floating Measurement
•Voltage Surge Measurement
•Power Electronics System Design
