Bourdon tube pressure gauges, liquid filled
case: stainless steel, model 213.53
Model: 213.53
Specifications according to data sheet: PM 02.12
Measuring system: copper alloy
Movement: copper alloy
Nominal size: 063 mm
Unit: MPa
Range: 0 MPa...25 MPa
Process connection: process connection : M14 x1,5 male
Connector position: center back mount
Case: stainless steel
Bezel ring: roll formed, stainless steel
Mounting flange/bracket: mounting bracket, galvanised steel
Window: acrylic (PMMA)
Accuracy class: class 1.6
Case filling: glycerine 99.7%
