详细说明
TR201-Z-13B-??-G140050?14TAZZ-ZZ
T31.10.1P2-1F-Z
TR201 Thread mounted resistance thermometer with
fabricated thermowell
Specifications according to data sheet: TE 60.15
Type and number of sensors: 1xPt100, -50 ... +250 ??C,
Sensor method of connection: 3 wire
Sensor limiting error: class B per DIN EN 60751
Process connection: M14x1,5
Design of process connection: male thread
Thermowell material: Mat.=stainless steel 1.4571
Thermowell outer diameter: 9 mm
Insertion length: 50 mm
Neck length: 0mm
Connection head: model BS (aluminium)
Cable entry to connection head: M20 x 1.5
Transmitter: mounted on the measuring insert
Analogue temperature transmitter T31
process industry series
Model: T31.10
Specifications according to data sheet: TE 31.01
Signal output: 4 ... 20 mA, 2-wire-design
Input: resistance thermometer Pt 100
model: T31.10, head mounting
Explosion protection: II 1G EEx ia IIC T4/T5/T6 acc. directive 94/9/EG (ATEX)
Measuring range: 0 ??C ... 120 ??C
详情请咨询销售人员 QQ：2880469682 ， 电话：188169191
