产品型号： | C型高性能便携式拉曼 |
| 产品品牌： | ||
| 产品价格： | 面议 | |
| 所 在 地： | 上海 闸北区 | |
| 发布日期： | 2010-06-05 | |
 |
||
详细说明
C1型高性能便携式拉曼
Key Features 主要特点
High sensitivity
高灵敏度
High resolution
高分辨率
Portability
便携
USB interface connection
USB计算机接口
Optional external battery
外接电池可选
Optional handtop PC
掌上电脑可选
Laser 激光器
Cleanlaze™ technology
Adjustable power output
532nm, 785nm, and custom
Detector 检测器
2048 Linear Array CCD
E Cooled, Back-thinned, 2D Binning CCD
Spectral Range 光谱范围
175-3075cm-1(785nm laser)
175-3250cm-1(532nm laser)
Spectral Resolution 光谱分辨率
5.0cm-1 - 7.0cm-1
Dimensions 外形尺寸
17 x 34 x 23.4cm
(6.1 x 8.7 x 11.9in)
Weight 重量
~3kg (~6 lbs)
Software 操作平台
光谱仪采集软件
GRAMS/AI interface
Multiple data format
Easy data transfer
Applications 应用领域
Materials science research
Process monitoring
Polymer development
Polymorph analysis
Medical diagnosis
Minerals analysis
Fossils analysis
Paint & Pigment analysis
Ancient art analysis
Anti-counterfeiting
SERS
Surface contamination
Pollution analysis
Si Crystallinity
Solar cell analysis
C2型高性能便携式拉曼
Key Features 主要特点
High sensitivity
高灵敏度
High resolution
高分辨率
Portability
便携
Internal USB interface connection
USB计算机接口
Embedded PC with Network Capabilities
内置电脑
Laser 激光器
Cleanlaze™ technology
Adjustable power output
532nm, 785nm, and custom
Detector 检测器
2048 Linear Array CCD
TE Cooled
Spectral Range 光谱范围
65-3070cm-1(785nm laser)
65-3250cm-1(532nm laser)
Spectral Resolution 光谱分辨率
2.0cm-1 - 4.5cm-1
Dimensions 外形尺寸
41 x 22 x 30.3cm
(16.1 x 8.7 x 11.9in)
Weight 重量
~9.98 kg (~22 lbs)
Software 操作平台
光谱仪采集软件
GRAMS/AI interface
Multiple data format
Easy data transfer
Applications 应用领域
Materials science research
Process monitoring
Polymer development
Polymorph analysis
Medical diagnosis
Minerals analysis
Fossils analysis
Paint & Pigment analysis
Ancient art analysis
Anti-counterfeiting
SERS
Surface contamination
Pollution analysis
Si Crystallinity
Solar cell analysis
